ND156TH19201080-A1 | 15.6 Inch IPS Display Full HD 1920x1080 MIPI LCD Module for Industrial & Automotive & Medical
The 15.6 inch IPS display module (ND156TH19201080-A1) is designed for applications where large-size visuals, high resolution, and reliable performance are essential. Featuring a 1920×1080 Full HD resolution and IPS panel technology, it delivers vibrant colors, sharp details, and wide full viewing angles, making it perfect for HMI systems, medical equipment, gaming monitors, industrial control, and professional displays.
With a MIPI 2T interface and 30-pin connector, this display integrates seamlessly into modern embedded systems. It features smooth and stable operation. An optional touchscreen provides interactive functionality, expanding its use for control panels, kiosks, and advanced embedded designs.
The module offers a 250 cd/m² brightness level, operates on a 5.5V supply voltage, and maintains durability with an operating temperature range of -10°C to 50°C. Its slim outline (350.56 × 205.15 mm) and large active area (344.16 × 193.59 mm) provide an impressive viewing experience for large-format applications.
Whether for industrial-grade equipment or STM32 or Rapberry Pi-based projects, this 15.6-inch Full HD IPS display delivers the perfect balance of clarity, size, and reliability to support your next-generation designs.
Specifications
| Part No.: | ND156TH19201080-A1 |
| Size: | 15.6 inch |
| Display Format: | 1920×1080 Resolution |
| Display Type: | IPS Display |
| Display Mode: | Transmissive |
| Touchscreen: | No (Optional with Yes) |
| Optimal View: | Full View |
| Outline Dimension: | 350.56*205.15 |
| Active Area: | 344.16 (H) ×193.59 (V) mm |
| Supply Voltage: | 5.5V |
| Luminance | 250 cd/m² |
| Interface: | MIPI 2T |
| Connection Type: | 30 pin connector |
| Compatibility: | Arduino and similar development boards |
| Operating Temperature: | -10°C ~ 50°C |
| Storage Temperature: | -20°C ~ 60°C |
| Mount Frame: | None |
Interface Definition
| NO. | Symbol | Description |
|---|---|---|
| 1 | NC | NC |
| 2 | H_GND | Ground |
| 3 | LANE1_N | eDP RX Channel 1 Negative |
| 4 | LANE1_P | eDP RX Channel 1 Positive |
| 5 | H_GND | Ground |
| 6 | LANE0_N | eDP RX Channel 0 Negativ |
| 7 | LANE0_P | eDP RX Channel 0 Positive |
| 8 | H_GND | Ground |
| 9 | AUX_CH_P | eDP AUX CH Positive |
| 10 | AUX_CH_N | eDP AUX CH Negative |
| 11 | H_GND | Ground |
| 12 | LCD_VCC | Power Supply, 3.3V (typ.) |
| 13 | LCD_VCC | Power Supply, 3.3V (typ.) |
| 14 | BIST | Panel Self Test Enable |
| 15 | H_GND | Groun |
| 16 | H_GND | Ground |
| 17 | HPD | Hot Plug Detect Output |
| 18 | BL_GND | LED Ground |
| 19 | BL_GND | LED Ground |
| 20 | BL_GND | LED Ground |
| 21 | BL_GND | LED Ground |
| 22 | BL_ENABLE | LED Enable Pin(+3.3V Input) |
| 23 | BL_PWM | System PWM Signal Inpu |
| 24 | NC | No Connection |
| 25 | NC | No Connection |
| 26 | BL_POWER | LED Power Supply 10.8V-13.2V |
| 27 | BL_POWER | LED Power Supply 10.8V-13.2V |
| 28 | BL_POWER | LED Power Supply 10.8V-13.2V |
| 29 | BL_POWER | LED Power Supply 10.8V-13.2V |
| 30 | NC | No Connec |
Custom 15'' TFT Display
We provide complete customization of TFT 15.6'' LCD display modules, offering flexible options in resolution, brightness, interface, and touch integration. Our services include PCB design, connector adjustments, and cover glass customization, ensuring precise compatibility and dependable performance for your application.
LCD Connector Custom
Modify LCD cable length and connector placement to fit your system requirements. Built for secure, efficient connectivity and seamless integration with 15.6” LCD displays.
Custom LCD Interfaces
Select from MCU parallel, LVDS, SPI, RGB, HDMI, MIPI DSI, and more. Our experts help you choose and integrate the optimal LCD interface for 15.6” IPS display to match your project needs.
15.6'' LCD PCB Design
We design bespoke PCBs for 15.6” LCD panels, customizing dimensions, form factor, connector positioning, and circuit layout to achieve exact compatibility and seamless
15.6'' Touchscreen Adds
Upgrade your 15.6” TFT display with resistive or capacitive touch options. Designed for seamless integration, it provides responsive control and a more intuitive user experience.
