ND133THM1366768-A01 13.3-Inch 1366 × 768 IPS TFT LCD Module with eDP
The ND133THM1366768-A01 is a 13.3-inch IPS TFT LCD module with a 1366 × 768 resolution and eDP interface. It is designed for embedded and industrial systems that require a larger display area with an eDP-connected host platform.
The module is supplied without a touchscreen as standard. Its IPS panel should be evaluated together with the intended viewing direction, mechanical mounting structure, optical stack and system-level eDP configuration. The B133EW04 controller should be considered during display initialisation and host-side integration.
Key Features
- 13.3-inch IPS TFT LCD module
- 1366 × 768 resolution
- eDP interface
- B133EW04 controller
- No touchscreen in the standard configuration
- Frame-free configuration
Integration Considerations
Confirm the eDP lane configuration, connector and FPC requirements, power and timing sequence, mechanical dimensions and operating conditions before selection. For a project review, share the host platform, target quantity, enclosure drawing, display orientation and any touch or cover-lens requirements.
Display Drawing
Interface Definition
Custom 13.3-Inch IPS TFT Integration
We support project-specific integration of this 13.3-inch IPS TFT module, including eDP host review, cable and connector coordination, touch integration, and mechanical or PCB requirements where confirmed.
Cable and Connector Review
Cable length, pin layout and connector position can be reviewed against the eDP host design and mechanical assembly.
Interface Integration
Confirm eDP lane configuration, connector requirements and host timing before selecting this 13.3-inch module for a project.
13.3-Inch Display PCB and Mechanical Review
PCB shape, mounting structure and connector placement can be evaluated where project requirements are confirmed.
13.3-Inch Touchscreen Integration
Touchscreen integration can be evaluated with the cover lens, touch controller, FPC routing and enclosure design.
